Rugged Tablet PC-SR800



Po szczegóły zadzwoń pod numer
801 000 167

title=
Specyfikacja
Opis produktuTablet Rugged model SR800
Gwarancja- 24 miesiące
Opis



Właściwości:



Compact A4 size with bumper and Magnesium-Alloy Housing in high strength and rugged structure

Ideal size 10.4" XGA (1024x768) TFT with resistive touch screen/digitizer, outdoor readable

Intel Core Duo Processor Yonah Ultra Low Voltage 1.2GHz Processor

Built-in WiFi 802.11 a/b/g; Bluetooth 2.0 Class I; CF/ PCMCIA card slots to support UMTS/HSDPA/EDGE/ GPRS/GPS Card

Meet IP54 standard and compliant MIL-STD-810F

Wide temperature range operation (-20°C~ +60°C)

7 hours of long operating battery life

RS232 port for industrial device connection



Opis ogólny:





RUGGEDBOOK Tablet PC SR800 takes the best aspects of the tablet PC technology and improves it for high-performance mobile applications. Ideal industries are field service, public safety, construction, logistics, law enforcement, military, social welfare, transportation, health care, and hospitality.
SR800 is designed to meet the mobile computing needs and form-factor requirements of on-the-go professionals. Moreover, the rugged design of IP54 can resist against various conditions such as shock, vibration, spill, dust and dirt, hot, and damp. In addition, the magnesium enclosure is employed especially for harsh environments and physical stresses.
Features of SR800 are mid-sized, lightweight, ergonomic, and multiple integrated wireless technologies which includes EDGE/GPRS, 802.11 a/b/g, Class I Bluetooth, and GPS. Therefore, it has compatibility with any wireless network.
To sum up, SR800 is an ideal solution to reduce the damage, failure rate, overall cost, and dependence on wired desktops for data and application access. Moreover, SR800´s rugged nature provides the highest protection, productivity, profitability for both indoor and outdoor environment.



Specyfikacja:




Specifications:

Processor Ultra Low Voltage Intel Core Duo Yonah
1.2GHz (U2500) CPU
FSB 533MHz / Chipset: 945GME /
L2 Cache 2M Standard


Memory 1GB DDR II; optional 2GB (maximum)


Storage Shock proof mounted, 2.5" 250GB HDD


Display 10.4" XGA (1024x768) TFT LCD with resistive touch control panel;
Optional: Outdoor readable display
Optional: Dual mode resistive & digitizer touch panel


Audio PCI Audio with Azalia (HD) compliance; Internal microphone and speaker


Communications Internal 56K V.92 Fax/Modem;
Internal Giga bit Ethernet LAN


I/O Port 2 x USB 2.0 port; 1 x Mini USB 2.0 port; 1 x RS-232 port; DC-In jack;
Audio- in/out for microphone/earphone;
RJ-11 jack for 56kbps V.92/K56 flex Modem;
RJ-45 jack for 10/100/1000 LAN;
Cradle connector


Expansion Slots 1 x PCMCIA Type II slot; 1 x Compact Flash Type II slot


Buttons One five-way control key and four button key;
One reset button; One digitizer/ resistive Switch; One power button


Wireless Communication Integrated WiFi 802.11 a/b/g &
Bluetooth 2.0 Class I + EDR


Optional PC Card WWAN 3.5G; GPS support


Power System Input: 100V-240V, 50-60Hz, Output: 65W/20V


Battery Li-Ion Battery 7200mAh,
Max. 7 hours battery life (in Windows XP Power Management setting).
Battery Mark Rev. 4.01: Life Test is 05:28 hrs,
Condition Run is 04:35 hrs.


Operating System Microsoft Windows XP Tablet Edition 2005
Microsoft Windows Vista Business ready


Environmental
Reliability
Meet MIL-STD-810F (Drop test / Vibration / Shock /Altitude / Temperature)
Meet IEC 60529 Edition 2.1 (Water proof / Dust proof)


Temperature Operating: -20°C to + 60°C, Storage: -20°C to +70°C,
(Cold boot: 0°C)
Humidity: 10o/o-95o/o


Dimension &
Weight
N.W.: 2.2 Kg, 284 x 209 x 63 mm (included 4 bumper / with battery)
G.W.: 3.4 Kg, 350 x 140 x 345 mm packed carton box


EMI/ Safety FCC (SAR certificated), CE, TUV, cUL, BSMI, CB



Porty wej./wyj.:





Akcesoria:



BR668VHMT011

BR800PURA010

VR6680100069


VR8000100017

V7178GPS-SAM

VR8000000004


VR8009510001

MR6685020001

BR668CARY010


M56221010002

VR668BAT0001

BR668BELT010


VR6680100094

BR6680000010

BR668CFPC010


VR8009530001

AR800001-SAM
































































































































































Zastosowanie:



Field Service



Ruggedbook tablet PC is detailed designed to ensure complete survivability in the field. It comes with a universal AC/DC adaptor and car adaptor/charger. On-the-go professional can run multiple software simultaneously, knowing the battery lasts 7 long hours (in all radio frequencies off status). Our advanced technologies present a high performance, low power consuming and low thermal output server.

Mid-sized, lightweight, ergonomic and comes with multiple integrated wireless technologies. The configurable bandwidth allows personnel to configure web-streaming performance to make the best use of available bandwidth. Water proof, dust proof, drop resistant and vibration resistant; completely featured for indoor and/or outdoor usage.





Government



In the air force, army, navy, there is no room for excuses of why things can´t be done, only room for solutions. Our Ruggedbook have been pushed to the limit in testing to meet stringent protocols.

To guarantee durability for various air, surface, and submergible vessels, our computer adheres to international protection ratings and various military standards-including shock, vibration and humidity. It also has an outdoor sunlight readable display with high resolution, ideal for graphic intensive application. For increased reliabilities in mission critical situations, Ruggedbook allow access even when server´s system goes offline. Our integrated Bluetooth and microphone/speaker allows wireless data/voice communication in-between Ruggedbook consoles. An integrated modem allows emergency access when the network or Internet is unavailable.



Construction & Manufacturing



On a daily basis, construction workers have numerous precautions to follow through at construction sites. Our computers help ease the workers´mental workload. Rugggedbook is the best companion at any construction site as it will smoothly survive through any heavy duty handling.

At sophisticated precision required industries; appraisers, engineers, contractors, architects need access to software in a single do-it-all unit. Ruggedbook meet and exceed the professional expectation. Now you can do more with less.

To provide remote, unblock access on the job site- it is compatible with any wireless network for maximum security, stability and speed.

With high XGA (1024 x 768)TFT LCD resolution, it is great for graphic intensive applications. The display also supports dual mode option between Resistive & Digitizer Touch Panel, which gives maximal control for detail oriented projects and technical blue prints.





Transportation







Where there is demand, there is supply. Smooth, prompt delivery of the supply to the demand means higher profit margin. Without advanced mobile communications, proper fleet management is impossibility.

Our computers can decrease downtime as it provides space management when mounted in cargo transporting vehicles. We can help to predict and solve the unpredictable; temperature, spills, dust and dirt. Even during air turbulences, our computer is drop certified and is shock resistive with bumper and magnesium-alloy housing in high strength and rugged structure. Operators can use the rugged touch screen, voice or text messaging.







Logistics



Real-time control of business assets and available resources gives competitive advantage to the company. No matter what state of challenging work environment is present, order and inventory information needs to be assessed and entered on-the-spot.

At warehouses, produce and poultry freshness time is swift, therefore, it is not a time or place for flimsy equipments to prolong transaction time. Ruggedbook is built for these demanding environments, a equipment you can trust. With characteristics to withstand wide temperature range between -20°C to +60°C and built rugged enough to withstand whatever dust, spills, dirt, jolts.











Hospitality:



Differentiate your corporation from others by having higher staff productivity and satisfaction.

Casinos:
Reliable, mobile access to player rankings for floormen and dealers. Remain in constant communication with central control units for images of potential suspects and banned guests.
Instantly keep-in-touch to announcements and policies.

Lodging (hotel, motel, bed & breakfast):
Professional and personal check-in/ check-out Wireless access promotes streamline hospitality management system Expanding guests´ interest and online coverage will increase hotel´s revenue on equipment utilization fees. Promote customer loyalty as customers experience individualized service offerings.

Restaurant chains, Food services:
Mobile, precise inputs for guest reservation and employee schedule change. More accurate course change updates for guests, waiters and the kitchen. Higher productivity levels when mobile. Earn public admiration for the restaurant´s well-disciplined management system.

Travel- Cruise line:
Mobile confirmation checklists of guest, luggage, cargo on board. On-the-spot documentations of required facility repair.





Retailing:



The back inventory management and the front service are the critical issues for retailing industry. Therefore, the necessity and features of assistant instrument is important.

RUGGEDBOOK provide functions of barcode scanner, RFID reader and camera. Moreover, the communication includes integrated WLAN, Bluetooth, GPS and GPRS. With above characteristics and easy-to-carry feature, the back managers are able to accurately track/manage inventory, and operate store efficiently. At front service, RUGGEDBOOK is applied for point-of-sale promotion tracking that staffs can provide instant services anywhere for customers in terms of sales figures and product prices.

It helps to build more person-to-person contact with customers that it strengthens customer satisfaction.
